*Integral gantry structure, dual AC Servo motor high speed synchronization system.
*Light high-rigidity aluminum alloy beamand Zaxis slide carriage ensured great
dynamic performance.
*Professional CNC laser cutting system.
* High accuracy, speed and stability bring byGermany precision linear guide, reduction box and helical gear transmission system.
*Lubricating in concentration and dust removing in partition to make sure themachine operates stably in long time.
*Mechanical high speed dual exchange table.
*Zoom perforation function.
*Cutting quality is optional in intelligent control system.
*Integrated structural design covers smaller area.
| Model | Unit | MK-3015E | MK-4020E | MK-6020E | MK-6025E | customization |
| Cutting Range | mm | 1500x3000 | 2000x4000 | 2000x6000 | 2500x6000 | |
| X Axis Stroke | mm | 1525 | 2025 | 2025 | 2525 | |
| Y Axis Stroke | mm | 3050 | 4050 | 6050 | 6050 | |
| Z Axis Stroke | mm | 300 | 300 | 300 | 300 | |
| XY Axis Positioning Accuracy | mm | ±0.03 | ±0.03 | ±0.03 | ±0.03 | |
| Repeat Positioning Accuracy | mm | ±0.03 | ±0.03 | ±0.03 | ±0.03 | |
| Maximum Acceleration | m/s2 | 1.5 | 1.5 | 1.5 | 1.5 | |
| Laser Power | W | 1500/3000/6000/8000/12000/15000/20000/30000/80000 | ||||
